CASE NZXT ATX Mid-Tower H9 FLOW w/2xWINDOWS + Top MESH, 4x F120Q Quiet Airflow fan ,USB-C 3.2, 2xUSB-A 3.2, Matte White CM-H91FW-01ID EK000696385

Model Name: NZXT H9 FLOW

Specification

• Motherboard Support: Mini-ITX, Micro-ATX, ATX
• Enclosure Type: Mid-Tower
• Case Material: SGCC Steel, Ultra-clear Tempered Glass, Dark Tinted Tempered Glass (Black only)
• DIMENSIONS: Height:495mm (With Feet), Width:290mm, Depth:466mm, Weight:12.1 kg

COMPATIBILITY & CLEARANCE

• Max CPU Cooler Clearance: Up to 165mm
• Max GPU Clearance: Up to 435mm
• PSU Clearance: 200mm
• Cable Management: 91mm

FRONT I/O PORTS:

• USB 3.2 Gen 1 Type-A: 2
• USB 3.2 Gen 2 Type-C: 1
• Headset Audio Jack: 1

EXPANSION SLOTS:

• Standard: 7
• Vertical: 0

DRIVE BAYS:

• 2.5": 4+2
• 3.5": 2

FAN SUPPORT:

• Side: 3 x 120mm
• Top: 3 x 120mm / 2 x 140mm
• Bottom: 3 x 120mm / 2 x 140mm
• Rear: 1 x 120mm
• Filters: All Air Intakes

RADIATOR SUPPORT:

• Side: Up to 360mm with Push/Pull
• Top: Up to 360mm
• Bottom: Up to 360mm
• Rear: Up to 120mm

FAN SPECS:

• Model: F120Q (Case Version)
• Speed: 1200 ± 240RPM
• Airflow: 62.18 CFM
• Static: 1.05 mm - H2O
• Noise: 25.1 dBA
• Fan Connector: 3-pin
