CASE PHANTEKS E-ATX full-Tower NV7 w/Tempered glass, D-RGB Illumination,White, PH-NV723TG_DMW01ID EK000696285

Model Name: PHANTEK NV7

Specification

• Case Dimension (D x W x H): 532 x 253 x 586 mm / 20.9 x 10.0 x 23.1 inch
• Form Factor: Full Tower
• Materials: Steel Chassis, Tempered Glass front and side panels
• Motherboard Support: ATX, micro-ATX, mini-ITX, SSI-CEB, E-ATX (up to 277 mm wide with LED Cover)
• Front I/O:
  • 1 x USB 3.2 GEN 2 Type-C
  • 2 x USB 3.0
  • D-RGB Mode button
  • D-RGB Colour button
  • D-RGB Speed button
  • D-RGB Channel button
  • Power button
  • Microphone / headphone Combo
• Connectors:
  • Power SW (Power Switch)
  • Power LED
  • USB 3.0
  • USB 3.2 GEN 2 Type-E
  • HD-Audio
  • 2 x D-RGB Channel A
  • 2 x D-RGB Channel B
  • D-RGB Motherboard Input
  • 2 x SATA Power
• Window: Yes, Front and Side Tempered Glass
• Expansion & Drive Bays:
  • PCI Slots (Expansion Slots): 8
  • Internal 3.5” Bay: 2 (1 x if all SSD positions are used)
  • Internal 2.5” Bay: 6 (4 x if both HDD positions are used)
• Vertical GPU Support: Yes, with optional bracket PH-VGPUKT4.0_03 or riser cable
• D-RGB Controller Output: 7 A per Channel, 4 A per port
• Cooling - Fans:
  • Side Fan: 4 x 120 mm
  • Bottom Fan: 3 x 120 mm / 3 x 140 mm
  • Top Fan: 3 x 120 mm
  • Rear Fan: 2 x 120 mm
• Liquid Cooling - Radiators:
  • Side Radiator: Up to 360 mm
  • Bottom Radiator: Up to 360 mm / Up to 280 mm
  • Top Radiator: Up to 360 mm
  • Rear Radiator: Up to 240 mm
• Clearances:
  • GPU Length: 450 mm
  • CPU Cooler Height: 185 mm
  • PSU Length: 255 mm
  • Side 360 Radiator Maximum Size: 132 x 440 mm
  • Side 360 Radiator Thickness: 65 mm (to GPU)
  • Top 360 Radiator Maximum Size: 132 x 440 mm
  • Rear 240 Radiator Maximum Size: 132 x 320 mm
  • Bottom Radiator Maximum Size: 140 x 440 mm
