PSU 850W SEASONIC G12 GM-850 80+ GOLD , Semi Modular, Black, SSR-850FMID EK000696653

Model name: SEASONIC G12 GM-850

Specifications:

_x000D_
• 80PLUS® Certification: Gold
_x000D_
• Cybenetics Efficiency Level: TBA
_x000D_
• Cybenetics Noise Level: TBA
_x000D_
• Form Factor: ATX/EPS
_x000D_
• Dimensions: 140 × 150 × 86 mm
_x000D_ _x000D_
• Fan Information_x000D_
  _x000D_
  • Fan Size: 120 mm
  _x000D_
  • Fan Control: Smart and Silent Fan Control
  _x000D_
  • Fan Bearing: Sleeve Bearing
  _x000D_
  _x000D_
_x000D_ _x000D_
• Cable Information_x000D_
  _x000D_
  • Modularity: Semi-Modular
  _x000D_
  _x000D_
_x000D_ _x000D_
• Electrical Features_x000D_
  _x000D_
  • Operating Temperature: 0 - 50 °C (derating from 100% to 80% from 40 °C to 50 °C linearly)
  _x000D_
  • MTBF @ 25 °C (excluding fan): 100,000 hours
  _x000D_
  • AC Input: Full Range
  _x000D_
  • Protections: OPP, OVP, OCP, SCP, OTP, UVP
  _x000D_
  _x000D_
_x000D_ _x000D_
• Safety and Environmental Compliance_x000D_
  _x000D_
  • Safety and EMC: cTUVus, TUV, CB, CCC, BSMI, CE, FCC
  _x000D_
  • Environmental Compliance: Energy Star, RoHS, WEEE, ErP Lot 6, REACH
  _x000D_
  _x000D_
_x000D_ _x000D_
• Power Output_x000D_
  _x000D_
  • AC Input: 100 V - 240 V | 10 - 6 A | 50 Hz - 60 Hz
  _x000D_
  • DC Output:_x000D_
    _x000D_
    • +3.3V: 20 A | 100 W
    _x000D_
    • +5V: 20 A | 100 W
    _x000D_
    • +12V: 70 A | 840 W
    _x000D_
    • -12V: 0.3 A | 3.6 W
    _x000D_
    • +5VSB: 2.5 A | 12.5 W
    _x000D_
    _x000D_
  _x000D_
  • Total Continuous Power: 850 W
  _x000D_
  _x000D_
_x000D_
