MB AM5 B850 EAGLE WIFI6E GIGABYTE 4xDDR5 8200Mhz (O.C), DP, HDMI, PCI-Ex16 4.0, 3xPCI-Ex16 3.0, 3xM.2, 4xSATA3, Wi-Fi 6E, BT 5,3ID EK000719457

Model Name: GIGABYTE B850 EAGLE WIFI6E

Specification :

• CPU
  AMD Socket AM5, support for:
  • AMD Ryzen™ 9000 Series Processors
  • AMD Ryzen™ 8000 Series Processors
  • AMD Ryzen™ 7000 Series Processors
• Chipset
  AMD B850
• Memory
  • Support for DDR5 8200(O.C) ... 4400 MT/s memory modules
  • 4 x DDR5 DIMM sockets supporting up to 256 GB
  • Dual channel memory architecture
  • Support for non-ECC Un-buffered DIMM
  • Support for AMD EXPO™ and XMP modules
• Onboard Graphics
  • 1 x DisplayPort, up to 3840x2160@144 Hz
  • 1 x HDMI port, up to 4096x2160@60 Hz
• Audio
  • Realtek® Audio CODEC
  • High Definition Audio
  • 2/4/5.1/7.1-channel
• LAN
  Realtek® GbE LAN chip (1 Gbps)
• Wireless Communication module
  • Intel® Wi-Fi 6E AX210
  • Realtek® Wi-Fi 6E RTL8852CE
• Expansion Slots
  • 1 x PCIe x16 from CPU (varies by processor)
  • 3 x PCIe x1 from chipset (PCIe 3.0)
• Storage Interface
  • 3 x M.2 connectors (varied PCIe versions)
  • 4 x SATA 6Gb/s connectors
  • RAID 0, 1, 5, 10 for NVMe
  • RAID 0, 1, 10 for SATA
• USB
  • CPU: 1 x USB-C (Gen1), 2 x USB 3.2 Gen2 Type-A
  • Chipset: USB-C (Gen1), 4 x USB 3.2 Gen1, 4 x USB 2.0
  • Chipset+Hub: 4 x USB 2.0 via headers
• Internal I/O Connectors
  • Power, fan, RGB, M.2, SATA, USB headers, TPM, buttons, jumpers
• Back Panel Connectors
  • DisplayPort, HDMI, USBs, RJ-45, PS/2, audio jacks, Q-Flash
• I/O Controller
  iTE® I/O Controller Chip
• H/W Monitoring
  • Voltage, Temperature, Fan speed, Water flow, Warnings
• BIOS
  • 1 x 256 Mbit flash
  • AMI UEFI BIOS (PnP, DMI, SM BIOS, ACPI)
• Bundled Software
  • Norton® Internet Security (OEM)
  • LAN bandwidth management
• Operating System
  • Windows 11 64-bit
  • Windows 10 64-bit
• Form Factor
  ATX; 30.5cm x 24.4cm
